OUR Top grade Machines
At Panna Lal & Company, we utilize cutting-edge steel processing machinery to ensure high-precision cutting, shaping, and customization of iron and steel products. Our machines are designed to enhance efficiency, reduce waste, and deliver superior quality steel solutions for various industries, including construction, automotive, solar, and PEB.
Cut to length machine 1
Specifications
HR Coils & HRPO are cut
Thickness 1.2mm to 6mm
Width 750mm to 2100mm
Automatic stacking
Cut to length machine 2
Specifications
HR Coils, HRPO Coils, CR Coils, GP Coils and GL coils are cut
Provides flat and wrinkle free material of grade 1 and grade 2 coils
Thickness from 0.3mm to 3mm
Width 750mm to 1650mm
Automatic stacking
Cut to length machine 3
Specifications
HR coils are cut
Thickness from 2.8mm to 16mm
Width from 900mm to 2200mm
Automatic stacking
2 levelers along with convex roller
Provides flat and wrinkle free material for grade 1, grade 2, rsp coils and bokaro coils.
Have a printing and stamping machine attached to it
Cut to length machine 4
Specifications
HR coils are cut.
Thickness from 5mm to 28mm.
Width from 900mm to 2800mm.
Automatic Stacking.
2 levelers along with convex roller
Top Notch machinery that can even process special grades such as BSK46,YS550, YS 700 and YS 900 without any wrinkles, side lose and any other defect
A printing machine attached for stamping.
Cut to length machine 5
Specifications
HRPO Coils, CR Coils, GP Coils and GL coils, PPGI and PPGL coils are cut
Provides flat and wrinkle free material with proper accuracy especially designed for Auto components, electrical appliances and stamping.
Thickness from 0.3mm to 3mm
Width 750mm to 2200mm
Automatic stacking
Slitter Machine (STAM, Italy)
Specifications
CR/HR coils are slitted
Thickness from 0.8mm to 6mm
Width uptil 1700mm
Automatic stacking
Sheering along with proper leveler & pinch roll
Provides flat and wrinkle free material for grade 1, grade 2, rsp coils and bokaro coils.
Can slit upto 20 sizes at 1 point of time.
5 part slitting can be done
Embossing machine
Specifications
Provides Willow flower on HR sheets
Thickness from 1mm to 5mm
Width from 750mm to 1500mm
Popularly know as chequered machine
NC Hydraulic shearing machine
Specifications
HR, CR, GP & EMBOSSED sheets are cut.
Thickness from 0.5mm to 10mm
Width up to 3100.
